A Time for Change

For the last three and a half years, I’ve been privileged to work at the greatest software company in the world; Microsoft. During that time, I launched a standards-based web development site (scriptjunkie.com), worked with major product teams (Windows, Windows Phone & IE), partnered to launch initiatives that offered tremendous value to developers, represented MS at many events, and became the community bridge to the Internet Explorer team. I’ve learned a lot about building products, setting expectations, customer communications, and cross-org collaboration at a scale most haven’t experienced. It’s been challenging and rewarding.

But to me, the greatest thing about MS is working with amazing people. People who care deeply about what they build and enabling users to do great things with their products. It’s easy to look at MS as a big monolithic entity and forget that there are incredibly passionate people working there WHO GENUINELY CARE. I’ve seen this first hand. So much greatness.

I’ve been fortunate to be a part of it. They even allowed me to do it remotely. At a time when so many companies are reining in their remote employees under the guise of “better collaboration” (read: we don’t trust you), Microsoft gave me the opportunity to have an excellent job while not having to uproot my family, suffer insane commutes and maintain great work/life balance. And let’s not forget the world-class benefits which are the icing on the cake.

I would recommend this company to anyone in a heartbeat because they truly care about their employees.

When Opportunity Knocks…

Even when things are going great, life sometimes throws you another option that you simply have to explore. And that’s what happened to me.

Beginning December 2nd, I will be taking on a leadership role in Telerik’s Developer Relations team working to create a unified developer outreach strategy for the company along with relevant and consistent outbound messaging for Telerik’s growing product lines. These products span enterprise and web audiences helping them target:

  • Desktop Development
  • Web apps
  • Mobile
  • Collaboration
  • Software Testing
  • Content Management

and are complemented with services and support that help upramp customers quickly and make them successful. With 800+ employees and 11 offices worldwide, Telerik is well-positioned to continue to innovate quickly and offer new solutions as the industry evolves.

It’s a career opportunity that I’m incredibly excited about especially with a company that has an established track record of success and growth while maintaining a start-up, agile culture. That I already knew plenty at folks at Telerik (some former-Softies I worked with and many others from the conference circuit) and all raved about the company made my decision substantially easier. And the fact that they embrace the remote-work culture really helped seal the deal. So on to the next stage in my career.

My last day at Microsoft will be December 1st. Thank you Microsoft for a fantastic 3+ years.

And welcome Telerik, I look forward to contributing to your continued success.

Back at Microsoft…

What a whirlwind day it’s been. As I mentioned earlier, Friday was my last day at Microsoft so I could chase the dream of programming in Clipper and MS-DOS. I was just about to push the “Buy it Now!” button on an eBay auction for Clipper 3.5″ disks when I got the call from my former manager Jeff Sandquist promising an endless supply of Reeses Peanut Butter Cups and 30 26.5 ounce bottles of Nutella if I came back to Microsoft. He also said he would force Nishant to report to Clint going forward. It was an offer I couldn’t refuse so starting this afternoon, I’m back at my original role at Microsoft.

It was an exciting day indeed and I’ll look back on Clipper fondly but I know where I’m needed…at Microsoft and pushing for the open web!

On Leaving Microsoft…

PLEASE READ: Since a lot of people are still reading this post & thinking I actually left Microsoft, I’m adding this note to clarify that this was an April Fool’s joke. Please check the post date. :)

Friday was my last day at Microsoft. It was a bitter-sweet moment for me having been there for 3 years and feeling I’ve done my best to contribute to the web initiatives at this wonderful company. After chatting with my manager Jeff Sandquist, though, I realized that I wasn’t moving in the direction that I wanted and needed a change. It had nothing to do with the company and especially not my peers. I’ve been so fortunate to work with such an amazing, passionate and intelligent group of people, by far the best I’ve ever worked with…ever. And the things I’ve experienced, the work I’ve done and the places I’ve been have all made my time at MS completely worthwhile. It was one of the best decisions of my life to work at the greatest software company in the world. But I really needed to chase my passion and Microsoft wasn’t filling that need for me.

So starting today, I’m going to do just that. It could be that I just turned 45 but I don’t want to look back and live a life of regret for not chasing that dream and working in the technology which is my passion…Clipper.

I’ve realized that this “web” thing is getting stale and people are losing interest in it. It’s all about the desktop again and I want to make sure I’m on top of this new wave. I got my start programming Clipper and remember how powerful it was for building apps and I know it’s gonna be the comeback technology of the next 5 years. Features like t-browse, .dbf files, and the dBase syntax make it so incredibly powerful and an obvious choice for the next wave of immersive and scalable experiences. And I’m stoked because it looks like I can still snag a copy of the Funky lib for Clipper! Even Class(y) is free now! Open source FTW!

Thankfully, Amazon shows 8 used copies of Programming in Clipper 5 and I scored a copy of the Clipper 3.5″ disks on eBay so I should be good to go as soon as I buy a 3.5″ floppy for my desktop. Also, it’s badass that I won’t need to worry about complex OSes like Windows, OSX or Linux anymore. I can finally pop in my MS-DOS 4.01 disks and get back to the REAL terminal, not that fake stuff in those overpriced PCs everyone’s been buying lately! The great thing is that with PCs being as powerful as they are, I no longer have to worry about configuring himem.sys or emm386.exe to get as close to 640k as possible. Booyah!

I’m still going to keep some systems using Windows 8 and OSX around since I plan on using Clipper to build both Win8 and iOS apps. I may also write a Clipper lib to interface with Google Glass. MS-DOS in eyewear; huzzah! I’m sure I can link to them via an RS-232 cable or something.

I just want to close out in thanking all of my buds like @rainypixels, @allenjs, @jeffsand and @ClintRutkas for being supportive of my decision and for @shanselman for bringing me into the fold. You guys have been awesome.

My new company name will be called “I’m Seriously Not Crazy Enough to do This, LLC.”.

Wish me luck!

Submitting an Internet Explorer Bug to Microsoft

Today, I got this tweet by Patrick Kettner asking how to submit an IE bug report:

I’ve been asked this a number of times and this was a great opportunity to post the steps on how to do it.

I’m not going to sugar coat it because I personally think the process is WAY too complicated and I’ve complained to the IE team about this. Thankfully, they agree and are looking at how to streamline the process.

First time Submitting a Bug

If this is the first time submitting a bug to Microsoft, you’ll need to register on the Microsoft Connect site.

Go to Microsoft’s Connect site. You’ll need to sign in to use the site. It requires a Microsoft Live account. If you already have a Live account, then login and follow the steps below. If you don’t, you’ll first need to create one (you’ll be presented with that option). I’m not going to show you how to register for a Live account because it’s very straightforward. Yes, I hate the fact that you need to do this too but thankfully it’s a one-time deal.

Once you’ve created it, follow the steps below.

cap-1

When you’re back at the Connect homepage, do a search for “IE10 Public Feedback”:

cap-3

This will pull up the entry where you can join the IE10 Feedback group and submit bugs. You’ll see a “Join” link to allow you to do this:

cap-4

If this is your first time using Connect, you’ll be prompted with a registration page and profile setup pages. This is a one-time deal and you shouldn’t be presented with these pages next time around:

cap-reg

cap-5

cap-6

Once you’re through that you should come to the IE10 Public Feedback page. This is where you’ll start submitting feedback by clicking on the “Feedback” link:

cap-7

When the feedback page comes up, scroll down and you’ll see a big “Submit Feedback” button. Use that to submit your bug.

cap-8

Returning to Submit a Bug

If you’re coming back, I’m assuming you already have a Microsoft Live ID so sign in:

cap-1

and when you’re brought back to the Connect homepage, click on the dropdown in the upper right corner to go directly to the Internet Explorer Feedback Program page. No need to search for it when that shortcut is there:

cap-9

Submitting Good Feedback

Any software maker will tell you the same thing; provide detailed steps and a test case if possible to make isolating your issue as easy as possible. If you simply type, “My site doesn’t render in IE9″, you’re making things more difficult. Take the time to really isolate the problem and provide detailed, concise information so that the IE team can properly determine if it’s a bug and even if there’s a workaround.

I recommend using tools like JSBin or JSFiddle to provide live test cases for the IE team to look at.

Improving the Process

I know this can be a cumbersome experience and we’ve received a lot of feedback about how frustrating it is to submit a bug. The IE team is working on improving this so bear with us while this gets worked on.

Special thank to Patrick for the motivation to put this post up.

Making Internet Explorer Testing Easier with new IE VMs

When Microsoft first launched modern.IE and revamped the way that IE VMs were offered, I wrote up a post that talked about how to install them. Since then, the site has changed so it’s time to update this post to reflect not only the new UI of the site but the new method of downloading individual VMs.

If you haven’t heard about modern.IE, then definitely read up on it here:

Introducing modern.IE – Testing sites for Internet Explorer made easier

The New Way to get IE VMs

Up until now, if you wanted to test different versions of IE natively you had to download VPC images that would allow you to run virtual machines for the different versions of IE. It wasn’t a great solution because:

  • They were designed to be run in Microsoft’s Virtual PC software making it hard for non-Windows developers to use them.
  • They were broken apart into multiple, large download files

There were ways to use them on other OSes but it required some work or unofficial scripts to convert them. Either way, the IE VPCs weren’t very easy or convenient to use.

We wanted to make this easier so as part of the modern.IE project, we created a new set of VMs that targeted your OS and your VM-specific software.

When you hit the page “Test across browsers” page, scroll down until you see this:

vms

This is the section that helps you to choose the right OS and platform. Now, you’ll be able to choose your OS:

vm-os

then choose the VM software:

vm-platform

and download the VM with the version(s) of IE you’d like to install:

vm-options

You’ll need to download ALL of the files listed for the specific version of IE you’d like work with. Depending on which OS you’re using, you may see a combo of *.exe/*.rar files (Windows) or *.sfx/*.rar files (OSX/Linux). The *.exe & *.sfx are self-extractors which will look for all of the files and combine them into the single VM you’ll need.

The great thing about this process is that:

  • You can use the VM software of your choice
  • You only have to download the files once per VM. They can be reused to recreate the VM after 90 days.

Currently, we’re offering VMs that will run on:

  • Windows
  • OSX
  • Linux

The VM software choices are specific to the OS you choose:

  • Windows – Hyper-V, Virtual PC, VirtualBox & VMWare Player for Windows
  • OSX- VirtualBox, VMWare Fusion and Parallels
  • Linux – VirtualBox

One thing to note is that it’s best to use an updated version of the VM software, especially for the Win8 VMs. Otherwise, you may encounter issues with the VM software not being able to run the virtualized OS properly.

The IE versions being offered are:

  • IE6 on Windows XP
  • IE7 on Vista
  • IE8 on Windows XP
  • IE8 on Windows 7
  • IE9 on Windows 7
  • IE10 on Windows 7
  • IE10 on Windows 8
  • IE11 Developer Preview on Windows 7
  • IE11 Developer Preview on Windows 8.1

For all intents you can now test against a full copy of any version of Internet Explorer.

Extracting the Virtual Machine

Windows

Notice that for IE9 on Win7 for VirtualBox on Windows, I’ve downloaded 5 files.

extract

I need to run “IE9.Win7.For.WindowsVirtualBox.part1.exe” to kick off the extraction. This will prompt me for a destination folder to extract to:

extract-2

Note that once the extraction is completed, the dialog box just disappears and you won’t get a prompt that it’s done. Hop over to your directory and you should find the newly extracted VM file waiting for you:

yourvm

OSX

OSX users have it even easier because you can use cURL to pull down all the files in one swoop. Just look for the “Grab them all with cURL” link and click on it. It’ll give you a popup like this:

curl

Open up terminal, “cd” to the directory where you want to download the files and paste the link displayed to kick off the download. Easy peasy.

To extract the virtual machine, you’ll need to go into terminal and set execute permission on the .sfx file like this “chmod +x filename.sfx”. You can then kick off the extraction by running the file: “./filename.sfx”.

extract-osx

You can find fully detailed installation instructions for the downloaded VMs in this PDF.

Installing the VMs

The VMs may come with some minimum resource settings already preconfigured. Here’s what I recommend to ensure you get a decent performing VM:

  • Give your VM a minimum of 1GB of RAM
  • Give it the most amount of video memory possible

Remember that you’re VM is an OS and it needs resources. Unless you’re loading multiple VMs at the same time, a gig of RAM shouldn’t have a major adverse issue on a decent system. Also note that while IE9 & IE10 support GPU-enhanced rendering, don’t expect the same performance in your VM as you would get from a native system.

The VMs you download are in compressed format. Once you’ve got them on your computer, you should run the extraction executable I referenced above to extract them for use. This will create the virtual machine file that you’ll import into your VM software. Again, you can find fully detailed installation instructions for the downloaded VMs in this PDF.

VirtualBox on Windows

Installing on VirtualBox is usually as easy as double-clicking the .ova file that you extracted.

yourvm

When you do this, you should get a VirtualBox dialog like this:

vb-import

Click on the “Import” button and VirtualBox will do the rest. It’s really that simple.

VMWare Fusion

The VM software I use on OSX is VMWare Fusion so here are the steps I went through to setup the Win8/IE10 VM.

Click on the “Add” drop down to create a new VM:

vmware

Choose “Continue without disc”:

vmware-new

This should present you with a screen to “Use an existing virtual disk” which is exactly what you want to do:

vmware-choosevm

I chose the “Select to create a copy of it” so that my original download isn’t affected and it makes a copy in the default VMWare VM directory. When you select the image, it will display a prompt asking if you want to convert it to an updated format:

vmware-dontconvert

Don’t convert it. I tried to and it seemed to corrupt the VM.

Select the proper version of Windows. These are 32 bit versions of the OS so the standard OS selections are fine (i.e.: not 64-bit). At the “Finish” screen, click “Customize Settings” to give the VM a better name like “Win8 – IE10″ and from there, VMWare will beging the process of copying the disc to the default VM directory and present you with the new VM:

vmware-vmdone

Before you start the new VM, change the RAM settings so your VM won’t have any trouble starting up. Again, I recommend a minimum of 1GB of RAM:

vmware-vmsettings

Your VM should now be ready to use.

REALLY IMPORTANT: If you’re using a Win8.x-based VM, be sure to set your screen resolution in the VM to a minimum of 1366×768 if you want to be able to use Internet Explorer. Internet Explorer desktop can launch in smaller resolutions but IE10 for Win8 and IE11 Developer Preview for Win8.1 are a Windows apps and needs the higher resolution. You’ll also want this for testing snap mode.

VirtualBox on OSX

Chris Wharton has written up a quick guide on how to get the Virtualbox VMs running on OSX. Just follow the steps I outlined for extracting your VM and then follow Chris’ steps for installing in VirtualBox.

Time Limits on the VMs

All of the VMs have a time limit 90 days of total time from the moment you first use the VM. Basically it’s 30 days usage with two 30-day rearms. To rearm, go into a command prompt with Administrator privileges and type in “slmgr –rearm

At the end of the 90 days, you’ll be able to use the VM for an hour before it shuts down. At this point, you’ll need to decide if that’s okay or if you’d like to recreate the VM and use it for another 90 days. Remember, you can reuse the same files you originally downloaded to recreate the VM so don’t delete them (unless you just love downloading big files).

Functional Limitations

I’ve been told that these images aren’t crippled and in my testing, I was able to apply updates and do installs with no issues. I would HIGHLY RECOMMEND that you run Windows updates when you use these VMs to get the latest updates and patches. Also, install an anti-virus software. Microsoft Security Essentials is free and will do the trick. If you’re running a Windows 8.x VM, it comes with anti-virus already.

iOS to IE10 Metro: Building Cross-Browser Plugin-Free Experiences

I’ve had the good fortune of working with my friend Jonathan Sampson recently on figuring out how to help developers build plugin-free experiences. With IE10 Metro going plugin-free, it’s incredibly important to document steps to help developers provide their users with great experiences without the need for proprietary 3rd party add-ons.

If you’ve built a plug-in-free browsing experience for the iPad, a few changes will make it ready for the new IE10 plug-in-free experience on Windows 8. As more browsers adopt the plug-in-free approach, now is a good time to start thinking about it. I’ll show you how to do this in a few steps below by writing code that works well in all modern browsers.

Today we’re going to work with a MSNBC plug-in-free experience for rich media. It breaks down to two things: styles and scripts.

To modify the files of MSNBC, I will be using a proxy application known as Fiddler. You can download this tool from http://fiddler2.com. This tool allows me to modify remote files as though they were on my local machine. If you have direct access to your own site, you can ignore Fiddler, and work directly with your files. Fiddler provides a great way for testing changes without the risk of breaking your live site.

Step 1: Declare Standards mode and valid markup for modern browsers

In order to use the HTML5 elements we’ll be utilizing below, you’ll first need to ensure that you are operating in standards mode. One way to ensure this is to include the HTML5 doctype at the top of your document:

<!DOCTYPE html>

Step 2: Update your CSS vendor prefixes

The CSS language is constantly in a state of change as new features are suggested, updated, and standardized. In order to allow developers to learn how to use these new features, browser vendors typically offer experimental implementations via prefixed properties.

A key part of using vendor prefixes responsibly is to ensure that prefixes from each vendor are included in your site to allow for the broadest level of feature support. In many cases, especially when building an iPad-centric site, you may have focused solely on -webkit properties, omitting the prefixes which target other browsers such as -o, -ms, and -moz. The end result of this is that you greatly limit the target devices that can render your plugin-free site to as well as provide a degraded experience for users of other modern browsers, many of which could serve up equally engaging functionality.

For instance, we find the following on MSNBC:

background: -webkit-gradient(
  linear,
  left top,
  left bottom,
  color-stop(1, rgba(192,192,192,.6)),
  color-stop(0.5, rgba(0,0,0,.6))
);

With the growing trend towards an HTML5 plugin-free experience, it’s important to expand these rules to provide the vendor prefixes of other major browsers as well.

background: -webkit-linear-gradient(
  top, rgba( 0, 0, 0, 0.0 ) 0%, rgba( 0, 0, 0, 0.6 ) 50% );
background: -moz-linear-gradient(
  top, rgba( 0, 0, 0, 0.0 ) 0%, rgba( 0, 0, 0, 0.6 ) 50% );
background: -ms-linear-gradient(
  top, rgba( 0, 0, 0, 0.0 ) 0%, rgba( 0, 0, 0, 0.6 ) 50% );
background: -o-linear-gradient(
  top, rgba( 0, 0, 0, 0.0 ) 0%, rgba( 0, 0, 0, 0.6 ) 50% );
background: linear-gradient(
  top, rgba( 0, 0, 0, 0.0 ) 0%, rgba( 0, 0, 0, 0.6 ) 50% );

While more verbose but the benefits to broad browser feature support certainly outweigh the extra typing involved. In addition, there are a number of great tools that can break down this workload, such as SASS and Compass, -prefix-free, or even CSS Snippets in the upcoming Visual Studio 2011.

Also, if you’re working predominantly in JavaScript and would like to save time determining which features are supported by your client’s browser, review the instructions in A Best Practice for Programming with Vendor Prefixes on the IEBlog.

Step 3: Get rid of browser sniffing methods

There are two methods used to determine what the user’s browser and device are capable of. One method, which unfortunately is somewhat popular, is browser sniffing. This method consists of examining the navigator object for certain patterns or values.

if ( navigator.userAgent.indexOf("iPad") > -1 ) {
  // Load HTML5 Experience
} else {
  // Load Flash Experience
}

The above code looks at the user agent string for the value “iPad”, and if found delivers a plug-in-free HTML5 experience. Otherwise, it’s assumed you are on a device that has Flash installed. This will result in a broken experience for non-iPad users who are browsing with plug-ins disabled, even though their browser is capable of handling HTML5 features.

Here is an attempt to find the version of Internet Explorer.

if ( tests.IE ) {
  j = /msie.(\d\.\d+)/i;
  k = navigator.userAgent.match(j)[1];
}

The user agent string is tested for a pattern that attempts to target the version number. This pattern looks for a single digit, followed by a period, followed by any number of additional digits. While this test will find values like “MSIE 8.0” and “MSIE 9.0”, it will not identify the latest version of Internet Explorer, which identifies itself as “MSIE 10.0”, since only one digit is expected before the period.

These are just a couple examples of why browser sniffing is not a best practice. The user agent string is not immutable – it is a read-write value that is easily changed by plugins, or even the user. Most modern browsers include the ability to easily change this value from their development tools, which some users take advantage of to get around poorly-developed websites.

If we disable plugins, or visit MSNBC from a device/browser that doesn’t have Flash, we would expect it to attempt a plug-in-free experience. Unfortunately, this is not the case. Rather than seeing an HTML5 experience, we’re instead asked to download Flash. This is because the site puts the user in one of two categories: an iPad user, or a Flash-enabled user.

Feature Detection

Rather than trying to guess what a browser is capable of by sniffing its user agent string (which will fail you eventually), it is much wiser to actually test features directly in the browser. If you wanted to test the browser’s ability to deliver video and audio via HTML5, you could actually attempt to create these elements via JavaScript, and see if the browser understands them. This practice is called feature detection.

if ( !!document.createElement(“video”).canPlayType  ) {
  // Load HTML5 Video
} else {
  // Load Flash Video
}

In the above example, we start by testing whether the canPlayType method exists on our newly-created video tag. We’re using double-negation to cast the response to a boolean. If the browser understands what a video element is, the canPlayType method will be present. If the video element is unknown to the browser, the canPlayType method will not exist. If this test passes, we load our HTML5 video. If the test does not pass, we attempt to load Flash. Deeper feature detection could take place here, since Flash may not be on the machine, or may be disabled.

Feature detection is the preferred method of determining what a browser is capable of, since there is no guesswork involved. If the browser passes properly-constructed tests, it absolutely supports the features you would like to use.

Many great tools exist to provide feature tests for you. Once such tool, which provides over 40 tests, is Modernizr. This tool creates a global object called “Modernizr” which contains the results of your tests. With Modernizr, testing for HTML5 video support is extremely easy:

if ( Modernizr.video ) {
  // Load HTML5 Video
}

MSNBC engages in browser sniffing to see if the device accessing the page is an iPad or not. Our first step is to remove the browser sniffing code, and replace it with feature detection code.

Before we can modify browser sniffing code, we first need to locate it. While in Internet Explorer, pressing F12 will pull up our Developer Tools. Within the tools, open the Script tab and do a search for “userAgent”. This search will seek out any instance of this property name in all of the site’s script files. We’re interested in the result from line 41 of http://www.msnbc.msn.com/id/37156949/.

Now that we know what we want to edit, we can open up Fiddler and load up our traffic. Once Fiddler is opened, perform a hard-refresh (Ctrl+F5 in IE) on the MSNBC page. This results in all of the page sessions being listed in Fiddler.

Looking carefully, you’ll notice our resource is the third from the top. Next I will setup an AutoResponder for this session file so that anytime it is requested, my own custom file is substituted in the place of the server response:

  1. Right-click this session and select “Decode Selected Sessions” from the context menu.
  2. Select the AutoResponder tab on the right.
  3. Click the “Enable automatic responses” checkbox in the AutoResponder tab.
  4. Drag the selected session from the left panel into the AutoResponder tab.

At this point, you should have an entry within your AutoResponder tab with the following rules:

  • If URI matches: EXACT:http://www.msnbc.msn.com/id/37156949/
  • Then respond with: *200-SESSION_3

Right-click the entry in the AutoResponder and select Edit Response. In the popup that follows, switch to the SyntaxView tab where we will find the source for this file. As expected, line 41 contains our browser sniffing code:

if(!(navigator.userAgent.toLowerCase().indexOf("ipad")>-1)){
  // Flash Experience
}

Rather than test the contents of the userAgent, we’re going to instead look for support for the HTML5 video tag. Switch the above condition to the following:

if ( !document.createElement("video").canPlayType ) {
  // Flash Experience
}

This test checks to see if we cannot use the video element. If canPlayType comes back as undefined, it will be cast to true and the first code block will be entered, setting up the Flash experience.

Step 4: Update touch and pointer events

Safari supports both a touch event model and a mouse event model. Internet Explorer 10 groups touch, mouse, and stylus events into a single abstract item known as a pointer. In fact, Internet Explorer 10 is the first browser to work for all input types, across all devices. This abstraction cuts down drastically on the amount of effort involved to determine which event model you ought to bind to and how to detect user-interaction. This pointer is then handled through MSPointer events. If necessary, you can determine the type of pointer by accessing the pointerType property.

Due to the fact Internet Explorer doesn’t support Apple’s proprietary event model, which includes touch events like touchstart, touchmove, and touchend, MSNBC’s event listeners will need to be amended to listen for MSPointer events like MSPointerDown, MSPointerUP, and MSPointerMove.

Due to the difference in event model implementations, use a feature detection tool like Modernizr or code like this to target all major event models:

if (window.navigator.msPointerEnabled) {
  myCanvas.addEventListener("MSPointerMove", paint, false);
} else {
  myCanvas.addEventListener("mousemove", paint, false);
  myCanvas.addEventListener(“touchmove”, paint, false);
}

MSNBC only supports touch events, which we will need to change so that visitors who happen to be using a mouse can still interact with the page:

Our events are tied up in http://www.msnbc.msn.com/id/43662671/15:

document.addEventListener("touchstart", touchHandler, false);
document.addEventListener("touchmove", touchHandler, false);
document.addEventListener("touchend", touchHandler, false);

We’re going to update this to include the MSPointer events as well:

if (window.navigator.msPointerEnabled) {
  document.addEventListener("MSPointerDown", touchHandler, false);
  document.addEventListener("MSPointerMove", touchHandler, false);
  document.addEventListener("MSPointerUp", touchHandler, false);
} else {
  document.addEventListener("touchstart", touchHandler, false);
  document.addEventListener("touchmove", touchHandler, false);
  document.addEventListener("touchend", touchHandler, false);
  document.addEventListener("mousedown", touchHandler, false);
  document.addEventListener("mousemove", touchHandler, false);
  document.addEventListener("mouseup", touchHandler, false);
}

First we’re checking for the presence of pointers. Since the MSPointer covers the mouse, fingers, and pens, we don’t need anything else besides them. We fall back, if necessary, to provide both touch and mouse events.

Next we need to create cases for these event types in http://www.msnbc.com/id/44937131/. Currently, MSNBC starts with the following:

if ( event.type == "touchstart" ) {
  /* Start drag logic */
} else
if ( event.type == "touchmove" ) {
  /* Drag logic */
} else
if ( event.type == "touchend" ) {
  /* Complete drag logic */
}

We’ll modify this to listen for all of the registered event types:

if ( event.type.match( /(down|start)$/i ) ) {
  /* Start drag logic */
} else
if ( event.type.match( /move$/i ) ) {
  /* Drag logic */
} else
if ( event.type.match( /(up|end)$/i ) ) {
  /* Complete drag logic */
}

The above uses the match method and a series of regular expressions to determine which event was raised. If the event raised ends with a case-insensitive “down” or “start”, we begin our drag code. If the event ends with a case-insensitive “move”, we perform the actual drag logic itself. And lastly, if the event ends with a case-insensitive “up” or “end”, we end our dragging event. Note: other events may be caught here as well, like onresizeend and keyup. Be sure to consider this in your project.

The above is an implementation of Ted Johnson’s solution in Handling Multi-touch and Mouse Input in All Browsers.

The drag logic itself initially relies upon the event.targetTouches TouchList. This member does not exist in Internet Explorer. The drag logic attempts to gather the pageX and pageY properties from the first item in the TouchList, however in Internet Explorer these values are found directly on the event object.

var curX = event.targetTouches[0].pageX;

Using the logical OR operator, I instruct curX to hold the value of event.pageX as long as event.pageX is present on the event object. If this property is not found, look within the targetTouches list:

var curX = event.pageX || event.targetTouches[0].pageX;

If event.pageX is not found, we fall back to assigning the value of targetTouches[0].pageX to our variable.

Another important item to keep in mind is that this site initially responds to touchmove. When this event is raised while touching the playlist, the code attempts to reposition the playlist based upon your touch movement. There is no hovering when it comes to touch – you’re either touching, or you’re not.

Now that we have mouse events tied into this logic, we have introduced the possibility for hovering. So while touchmove is free to reposition our playlist when it is over the playlist, we don’t want to do the same for mousemove. In fact, we only want the mousemove event to reposition the playlist when the mouse button is pressed.

For further reading, and examples on how to target all browsers, see Handling Multi-touch and Mouse Input in All Browsers.

Testing both experiences

Recall our feature detection from earlier, how we first check to see if HTML5 video support is in the user’s browser. If it is, we give them HTML5. If it is not, we give them Flash. One easy way to test our work is to use a browser, or document mode, that doesn’t support HTML5 features. This is very easy to test with Internet Explorer:

  1. Press F12 to reveal the Developer Tools
  2. Change your Document Mode to Internet Explorer 7 Standards
  3. Refresh the page

If our feature detection condition was written properly, you should now be watching a Flash-based presentation. Switching your Document Mode back into Internet Explorer 9 Standards (or “Standards” if you’re using IE10), will return you to the HTML5 experience.

Get it Done!

Hopefully this post helps to define the types of changes that will allow your iOS site to work properly in IE10 Metro and other plugin-free environments. By including best practices such as feature detection and responsibly using vendor prefixes for great new features, you should be able to provide your users a great experience, regardless of which browser or device they’re using. To assist with testing in other plug-in-free environments, download Internet Explorer 10 (currently available only in the Windows 8 CP) and begin testing today!

Update: In the rush to get this post up, I realized that I forgot to thank and give credit to Jonathan Sampson for helping investigate and write about the great techniques mentioned above. He was a huge help in generating many of these great techniques. Thanks JS!

Fix Common IE Problems: Update your Docmode for Web Standards

Document compatibility defines how a browser renders your website. The more specific you are at telling the browser what to expect, the better the experience for your users. When using web standards like HTML5, start by explicitly declaring the HTML5 document type:

<!DOCTYPE html>

This markup triggers standards mode in Internet Explorer 9 and 10. And it also works well in Chrome and Firefox. Four steps will get your site ready for many browsers and devices:

Step 1: Validate that your site uses standards mode

Check whether or not your site is currently in standards mode:

  1. Open the website in Internet Explorer 10.
    • Note: You can also follow the same steps to update the docmode for IE9 only without downloading the preview.
  2. Press F12 to launch the IE Developer Tools or find it on the Tools menu as shown below:

    • Note: If you’re not familiar with using the IE F12 Developer Tools to debug your webpages, please read the following tutorial.
  3. Check if your site indicates Browser Mode: IE10 and Document Mode: IE10 standards as shown in the toolbar below:

    Click to Enlarge
  4. If your site is in Browser Mode: IE10 and Document Mode: IE10 Standards, you’re done! Note if the Browser Mode and Document Mode of your site are different than above. A common example is Browser Mode = IE8 and Document Mode = Quirks which indicates that your website was designed for older versions of IE and may not be ready for web standards.

    Click to Enlarge

Step 2: Implement docmode for web standards

Force IE10 standards mode to test your website:

  1. Insert
    <!DOCTYPE html>

    into your website’s HTML page

    • Learn more about how to update your doctypes here
  2. Reload your page in the browser and check the Browser Mode and Document Mode again using the F12 Developer Tools. If Browser Mode: IE10 and Document Mode: IE10 standards are not shown, continue below.

Step 3: Determine why your site is not in Standards Mode

Most problems are related to supporting older versions of IE. Start by ensuring your standards-based code is rendered in IE9 and 10. Then keep your non-standards-based code for older versions of IE.

  1. My page is not in Browser Mode: IE10

    • Possible Cause: Your website may flagged in Compatibility View and forced into an older browser mode to ensure the site functions
      • Resolution: Check if your site is on the list here. Learn more about the Compatibility View list and request removal here.
  2. My page is not in Document Mode = IE10
    • Possible Cause: Your website’s doctype is invalid or missing

      • Resolution: Check for a valid, well-formed doctype like:

        <!DOCTYPE html>
        <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd">
        <!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Strict//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-strict.dtd">

        Learn more about how to update your doctypes here.

      • Possible Cause: Docmode being forced via X-UA-Compatible meta tag

        • Resolution: Check for code similar to this in the of the page.

          <meta http-equiv="X-UA-Compatible" content="IE=EmulateIE7" >
          <meta http-equiv="X-UA-Compatible" content="IE=8" >

          Remove it and reload your page. Continue testing. Learn more about Specifying Document Compatibility Modes here.

Step 4: Resolve common IE problems when updating docmode

Most problems are related to supporting older versions of IE. Start by ensuring your standards-based code is rendered in IE9 and 10. Then keep your non-standards-based code for older versions of IE.

  • Possible Cause: Conditional comments support browser version-specific features

    • Resolution: Check for conditional comments that run non-standard code. These are often used on specific features supported by older versions of IE to allow the page to degrade gracefully. Check for code similar to this:

      <!--[if IE 8]>

      <p>Welcome to Internet Explorer 8.</p>

      <![endif]-->


      Remove it and reload your page. Continue testing. Learn more about Conditional Comments here.

  • Possible Cause: User agent sniffing supports browser version-specific features
    • Resolution: Check for user agent sniffing. These are often used to specifically target a browser based on the user agent string presented via the browser mode. Check for code similar to this:

      if (version = /MSIE (\d+\.\d+)/.exec(navigator.userAgent)) {

      	isIE = true;

      browserVersion = parseFloat(version[1]);
      }

      Start by implementing feature detection where possible with web standards. Learn more about User-Agent Strings here. The IE10 User-Agent String is located here.

Other reasons my page does not render correctly:

  • Possible Cause: Your website may be using browser specific features that are no longer supported. Use web standards whenever possible.

  • Possible Cause: Your website may be using 3rd party plug-ins or like Flash, Quicktime, and Silverlight that are no longer supported by the IE10 metro. Use web standards whenever possible.
    • Resolution: Learn how to create plug-in free experiences. A complete step-by-step guide will be available shortly.
  • Possible Cause: Your website may be loading browser version-specific CSS files:
    • Resolution: Ensure layout is avoiding CSS hacks where possible. Learn more about investigating CSS issues here.

A list of common problems is available in the IE Compatibility Cookbook.

If you’re unable to update your docmode with these resolution steps, tweet us @IE or check the Forums on MSDN.

For further detail, try these articles:

Site Pinning: Rotating Overlay Icons for Multiple Service Notifications

In my last post, I went over how to use IE9′s Site Pinning API to implement overlay icons to enhance user notifications. The demo focused on how to display a numeric icon to indicate when a specific event (e.g.: messages in an inbox) had occurred.


Pinned site with overlay icon

It’s a really great way of letting your users know that there’s pending information for them to check into. But what happens if your site offers multiple types of notifications? With websites offering so much functionality nowadays, it’s pretty common for them to also serve up multiple types of notifications, from friend requests and event reminders to new messages and game invites.

Rotating Multiple Overlays Icons

The great thing about the Site Pinning API is that it’s very flexible and through some JavaScript magic, you can easily display multiple overlay icons for the various services you have. In this demo, I want to rotate through 3 different overlay icons that alert the user to pending messages, requests and actions.

As before, I had to flex some of my artistic talent by creating the overlay icons using the x-icon editor. I created 5 of each and here’s how the first three look:

The code changed slightly from the last demo in order to accommodate multiple bits of data per fetch. While previously, I was only fetching one piece of data, in this demo, I’m returning 3, one for each notification type:

 myPin.init([{ "data" : [{ "label" : "Messages", "ntype" : "M", "num": 2 }, { "label" : "Requests", "ntype" : "R", "num": 1 }, { "label" : "Actions", "ntype" : "A", "num": 3 }] },
		        { "data" : [{ "label" : "Messages", "ntype" : "M", "num": 1 }, { "label" : "Requests", "ntype" : "R", "num": 5 }, { "label" : "Actions", "ntype" : "A", "num": 2 }] },
		        { "data" : [{ "label" : "Messages", "ntype" : "M", "num": 5 }, { "label" : "Requests", "ntype" : "R", "num": 1 }, { "label" : "Actions", "ntype" : "A", "num": 4 }] }
			   ]);

As a reminder, the method getData() simulates grabbing remote data. So if we look at the data above, we can simulate pulling back three distinct bits of data. This is why we call the method every 10 seconds using setInterval. This allows us to see how notifications might look over a period of time.

setInterval(function () { myPin.getData() }, 10000);

The next thing that changed is the use of a timer to allow a slight delay while rendering the overlay icons. Using setTimeout() provides enough of delay so that an individual overlay icon is visible to the user before rotating on to the next icon. If we didn’t have this delay, the rotation would be way too fast to provide any useful notification. If we look at the following image, we can see what the notification will look like:


Overlay icon showing numeric notification

This is accomplished via the following code:

// Grab the current set of data...
currData = this.dataBin[this.currIndex++].data;

/* We're going to display a new overlay every x number of seconds to display a new overlay icon so
   let's loop through the data elements for the current set of data... */
for (var i=0; i < currData.length; i++ ){

	(function(idx) { setTimeout( function(){ myPin.dispOverlay( currData[idx] ); }, 1000 * idx); }( i ));

}

Here’s what’s happening. In the first line, I grab the current set of data that holds all of the notification information (messages, requests & actions). That data looks like this:

[{ "label" : "Messages", "ntype" : "M", "num": 2 },
{ "label" : "Requests", "ntype" : "R", "num": 1 },
{ "label" : "Actions", "ntype" : "A", "num": 3 }]

I loop through each group of data and assign a timer using setTimeout() that will call dispOverlay() at ~1 second intervals. That’s the magic code that allows for the gradual icon rendering delay I mentioned before. The expected functionality is that the “messages” icon will render followed by the “requests” icon 1 second later, and then finally the “actions” icon.

Now, you might be wondering why I have an anonymous function wrapping the setTimeout(). It’s because I have a closure within setTimeout which can cause a common scoping issue in which the variable ‘i’, which I use to grab the current index of data, will only be updated to the last index value. James Padolsey has a great explanation on it and thanks to John David Dalton for helping me troubleshoot this.

The final change is in dispOverlay() in which I need to determine which overlay icon needs to display. Since I now have three different types of notifications, I need a conditional statement to determine the type and build the correct icon name:

if (theData.ntype == "M") {
	oImg = "images/messages-" + theData.num + ".ico";
} else if (theData.ntype == "R") {
	oImg = "images/requests-" + theData.num + ".ico";
} else if (theData.ntype == "A") {
	oImg = "images/actions-" + theData.num + ".ico";
}

This checks the type and serves up the right icon based on the type and the number of notifications pending for that type.

The Demo and Final Code

You can check out the demo by going here in IE9:

http://reybango.com/demos/sprotate/index.html

When the page renders, drag the tab down to your taskbar and pin it. You should see a new window appear with your newly pinned site. Next, you’ll see the overlay icons appear in the taskbar and they should begin to cycle every 10 seconds.

Here’s the full source code. You can also download everything here.

<!DOCTYPE html>
<html>
<head>
<title>Pinned Site - Rotating Overlay Icons</title>
<link rel="shortcut icon" type="image/ico" href="favicon.ico" />
<meta name="application-name" content="Pinned Site Test" />
<meta name="msapplication-starturl" content="http://reybango.com/demos/sprotate/index.html" />
<meta name="msapplication-navbutton-color" content="#3480C0" />
<meta name="msapplication-window" content="width=1024;height=768" />
<meta name="msapplication-tooltip" content="Testing the Pinned Site API" />
<style>
body {
    background: none repeat scroll 0 0 #4492CE;
    font: 440%/1.4em 'Segoe Light',Segoe,'Segoe UI','Meiryo Regular','Meiryo',sans-serif;
    color: #EDEFF4;
}

</style>

</head>

<body>

<div>
<h1>Pinned Sites</h1>
<p>Rotating Overlay Icons</p>
</div>

<script>

	var myData = [];

    var myPin = {

        currIndex: 0,
        dataBin: [],

        getData: function () {

			var idx = 0, currData = [], cntr = 0, theData;

            // Determines whether the current page was launched as a pinned site...
            if (window.external.msIsSiteMode()) {

				// Grab the current set of data...
				currData = this.dataBin[this.currIndex++].data;

				/* We're going to display a new overlay every x number of seconds to display a new overlay icon so
				   let's loop through the data elements for the current set of data... */
				for (var i=0; i < currData.length; i++ ){

					(function(idx) { setTimeout( function(){ myPin.dispOverlay( currData[idx] ); }, 1e3 * idx); }( i ));

				}

				if (this.currIndex > 2) { this.currIndex = 0 }

            }

        },

        dispOverlay: function (theData) {

            var oImg = "";

            // Is there any data?
            if (theData) {

                // Clear any preexisting overlay icon
                window.external.msSiteModeClearIconOverlay();

				// Render the overlay icon based on the data returned...
				if (theData.ntype == "M") {
					oImg = "images/messages-" + theData.num + ".ico";
				} else if (theData.ntype == "R") {
					oImg = "images/requests-" + theData.num + ".ico";
				} else if (theData.ntype == "A") {
					oImg = "images/actions-" + theData.num + ".ico";
				}

                // Go ahead and create the overlay image and it's label...
                this.setOverlay(oImg, theData.label);

            }

        },

        setOverlay: function (icon, desc) {

            // Sets the overlay icons...
            window.external.msSiteModeSetIconOverlay(icon, desc);
            window.external.msSiteModeActivate();

        },

        init: function (myData) {

            this.dataBin = myData;
			this.getData();

        }

    };

    // This clears out any previously set overlay icons...
    window.external.msSiteModeClearIconOverlay();

    // Run it once to kick everything off...
    myPin.init([{ "data" : [{ "label" : "Messages", "ntype" : "M", "num": 2 }, { "label" : "Requests", "ntype" : "R", "num": 1 }, { "label" : "Actions", "ntype" : "A", "num": 3 }] },
		        { "data" : [{ "label" : "Messages", "ntype" : "M", "num": 1 }, { "label" : "Requests", "ntype" : "R", "num": 5 }, { "label" : "Actions", "ntype" : "A", "num": 2 }] },
		        { "data" : [{ "label" : "Messages", "ntype" : "M", "num": 5 }, { "label" : "Requests", "ntype" : "R", "num": 1 }, { "label" : "Actions", "ntype" : "A", "num": 4 }] }
			   ]);

    // This is only here because I want to simulate pulling data on a regular interval...
    setInterval(function () { myPin.getData() }, 10000);

</script>
</body>
</html>

Using Site Pinning and Overlay Icons for Enhanced User Notifications and Engagement

I was recently doing some testing of IE9’s Site Pinning API and found out about a cool bit of functionality that can enhance user notifications. If you’re not familiar with site pinning, it’s a great way to allow users to have easy and quick access to their favorite sites via the Windows taskbar. There’s a really nice overview on Beauty of the Web that explains how it works.

Keeping Users Up-to-Date

One of the features the API provides is the notion of notifications that can allow developers to provide alerts to end users. The functionality allows you to dynamically insert custom overlay icons that can alert users when an important bit of information is available. These overlay icons are rendered over the favicon that is pinned to the taskbar. If you look at the image below, you can see it in action:


Pinned site with no overlay icon


Pinned site with overlay icon

So if you think about the possibilities, any site that offers users an inbox, special deals or sends out time-sensitive alerts could use this notification capability to keep their users up-to-date and more engaged on the site. Sites like the Huffington Post have already discovered that users that pinned HuffPost spent 49% more time on the site.

The best part is that adding this capability is insanely easy.

Setting it Up

For this post, we’re not going to go into the basics of how to pin a site. If you want to learn more, here’s a GREAT resource for getting you up to speed quickly: BuildMyPinnedSite.com. In fact, I used that site to help get me up-to-speed on the basics and it’s well-worth visiting.

To add notifications, you’ll need a couple of things:

  • A cool favicon for your site. If you don’t have one, you can use the handy web-based X-Icon Editor to create one.
  • A set of overlay icons to use. The recommended size is 16×16.

The API is JavaScript-based and we’ll use the following methods:

window.external.msSiteModeClearIconOverlay()
window.external.msSiteModeSetIconOverlay()
window.external.msSiteModeActivate()
window.external.msIsSiteMode()

The window.external.msSiteModeClearIconOverlay method is used to clear out any previously set overlay icons. window.external.msSiteModeSetIconOverlay allows you to specify the name of the notification icon as well as a accessible description. Lastly, we’ll use window.external.msSiteModeActivate to flash the pinned icon to notify the user of the update. Lastly, window.external.msIsSiteMode will let us know if the page was launched as a pinned site, thus allowing us to better determine when to run the code.

For the overlay icons, I’m using five images that display numbers 1 through 5 respectively to designate the number of messages are in a user’s inbox.

The Code

The first thing I need to add is the reference to my favicon. Note that if you don’t add one, then the Internet Explorer’s icon will be used by default.

<link rel="shortcut icon" type="image/ico" href="favicon.ico" />

Next, I want to create some sample data to work with. What I want to do for my demo is to have the overlay icon dynamically change every 5 seconds to simulate a more real-world scenario. The data is a simple array containing JSON data in each element.

myPin.init([{ "num": 1, "label": "Label 1" },
                { "num": 2, "label": "Label 2" },
                { "num": 3, "label": "Label 3" },
                { "num": 4, "label": "Label 4" },
                { "num": 5, "label": "Label 5" }
                ]);

By setting a timer, I’ll be able to pull a new set of data every 5 seconds.

setInterval(function () { myPin.getData(); }, 5000);

The main thing to keep in mind is that I’m “simulating” getting data from some remote host. In reality, all that the myPin.getData() method does is use a running counter to grab a new set of data and render a new overlay icon:

getData: function () {
            // A function that just simulates returning a result set...
            var idx = 0;

            // Determines whether the current page was launched as a pinned site.
            if (window.external.msIsSiteMode()) {

                idx = this.currIndex++;
                this.currIndex = (this.currIndex < 5) ? this.currIndex : 0;

                this.dispOverlay(this.dataBin[idx]);

            }

}

As you can see, it uses the running counter var currIndex to determine which array element to grab and then passes the data to dispOverlay(). This is where we use window.external.msSiteModeClearIconOverlay() to clear out any previously displayed overlay icons and also generate a string for the actual icon name. You can see that the oImg var is created on the fly based on the data we’re using.

dispOverlay: function (theData) {

            var oImg = "";

            // Is there any data?
            if (theData) {

                // Clear any preexisting overlay icon
                window.external.msSiteModeClearIconOverlay();

                // Create the image string...
                oImg = "images/num_" + theData.num + ".ico";

                // Go ahead and create the overlay image and it's label...
                this.setOverlay(oImg, theData.label);

            }

}

That icon name, along with the accessible label text for the icon, is passed to setOverlay() which sets the overlay icon via window.external.msSiteModeSetIconOverlay and flashes the taskbar icon using window.external.msSiteModeActivate.

setOverlay: function (icon, desc) {

            // Sets the overlay icons...
            window.external.msSiteModeSetIconOverlay(icon, desc);
            window.external.msSiteModeActivate();

}

Test it Out

To test this out, it’s a simple matter of running your newly pinned page in Internet Explorer 9, grabbing the tab and dragging it down to your taskbar:


Tab being dragged to the taskbar


Pinned site with no overlay icon

Five seconds after the page has been pinned, the code will fire off the first notification and continue to cycle through the other icons every subsequent five seconds.


Pinned site with overlay icon

An important thing to remember is that the IE F12 Developer tools are available to you to use in debugging your pinned site. So if you run into quirks, simply press the F12 key and the tools will appear.

The Demo and Final Code

You can check out the demo I whipped up by going here in IE9:

http://reybango.com/demos/sitepinning/index.html

When the page renders, drag the tab down to your taskbar and pin it. You should see a new windows appear with your newly pinned site. Five seconds later, you’ll see the first overlay icon appear in the taskbar.

Here’s the full source code. You can also download everything here. The really great part is that it isn’t a lot of code to implement this. In fact, to use the API only required 4 method calls. The bulk of the code was to simulate pulling in data. And the “>impact on user engagement is certainly worth adding in the capability.

<!DOCTYPE html>
<html>
<head>
<title>Pinned Site Test</title>
<link rel="shortcut icon" type="image/ico" href="favicon.ico" />
<meta name="application-name" content="Pinned Site Test" />
<meta name="msapplication-starturl" content="http://reybango.com/demos/sitepinning/index.html" />
<meta name="msapplication-navbutton-color" content="#3480C0" />
<meta name="msapplication-window" content="width=1024;height=768" />
<meta name="msapplication-tooltip" content="Testing the Pinned Site API" />
<style>
body {
    background: none repeat scroll 0 0 #4492CE;
    color: #EDEFF4;
}

h1 {
    float: left;
    font: 440%/1.4em 'Segoe Light',Segoe,'Segoe UI','Meiryo Regular','Meiryo',sans-serif;
    margin-left: 10px;
    position: relative;
}
</style>

</head>

<body>

<h1>Pinned Site Test</h1>

<div></div>

<script>

    var myPin = {

        currIndex: 0,
        dataBin: [],

        getData: function () {
            // A function that just simulates returning a result set...
            var idx = 0;

            // Determines whether the current page was launched as a pinned site.
            if (window.external.msIsSiteMode()) {

                idx = this.currIndex++;
                this.currIndex = (this.currIndex < 5) ? this.currIndex : 0;

                this.dispOverlay(this.dataBin[idx]);

            }

        },

        setOverlay: function (icon, desc) {

            // Sets the overlay icons...
            window.external.msSiteModeSetIconOverlay(icon, desc);
            window.external.msSiteModeActivate();

        },


        dispOverlay: function (theData) {

            var oImg = "";

            // Is there any data?
            if (theData) {

                // Clear any preexisting overlay icon
                window.external.msSiteModeClearIconOverlay();

                // Create the image string...
                oImg = "images/num_" + theData.num + ".ico";

                // Go ahead and create the overlay image and it's label...
                this.setOverlay(oImg, theData.label);

            }

        },

        init: function (myData) {

            this.dataBin = myData;

        }

    };

    // This clears out any previously set overlay icons...
    window.external.msSiteModeClearIconOverlay();

    // Run it once to kick everything off...
    myPin.init([{ "num": 1, "label": "Label 1" },
                { "num": 2, "label": "Label 2" },
                { "num": 3, "label": "Label 3" },
                { "num": 4, "label": "Label 4" },
                { "num": 5, "label": "Label 5" }
                ]);

    // This is only here because I want to simulate pulling data on a regular interval...
    setInterval(function () { myPin.getData(); }, 5000);

</script>
</body>
</html>

MIX11 Day 1 Recap: IE10 & HTML5

Day 1 at MIX11 was awesome. The vibe was excitely what I expected: awesome and exciting. And the keynte kicked it off with the big news that the next version of Internet Explorer is already in progress and that IE10
Platform Preview 1 is ready for download
. Since the launch of IE9, the concern that I’ve consistently heard from developers is that they expected to wait another 2 years before a new release of Microsoft’s browser. From the tweets I saw yesterday, it seemed like there was a collective sigh of relief to know that a new version is under way and that there’s something to play with right now. Couple that with the list of IE10 features announced like CSS3 3D Transforms & Transitions, Flexbox, and ES5 Strict Mode (and more), and I genuinely feel that developers are excited to see the great progress being made by the IE team. Shoot, even Douglas Crockford is happy! He’s at MIX and I made sure to ask what he thought and he mentioned that the addition of ES5 Strict Mode made him VERY happy…and WE WANT CROCKFORD HAPPY!! :D

Another really cool announcement during the keynote was that Modernizr will be shipped with the ASP.NET MVC 3 Tools update. The importance of this can’t be understated. Microsoft has millions of developers building web applications using their tools and the fact that Modernizr will be shipped in Microsoft tooling is a HUGE validation to the work done by the Modernizr team as well as the importance of HTML5 to the future of web applications.

HTML5 is a hot topic with a ton of sessions focusing on the specification. I’ll be presenting on HTML5 polyfills and shims tomorrow to show developers how to leverage HTML5 while still supporting sites in non-modern browsers. It’s incredibly exciting (and intimidating) to be presenting to such a large group of developer so wish me luck!!

Interestingly, I kept hearing people mention the Knockout.js MVC/MVVM Framework for managing your code organization and providing data-binding. I hadn’t heard of it so I’m definitely going to have to check it out.

More to come later….

#ms_mix11_w

Learn JavaScript!

What to Read to Get Up to Speed in JavaScript.

The best books & blogs for learning JavaScript development. Broken down by experience levels!


My BIG LIST of JavaScript, CSS & HTML Development Tools, Libraries, Projects, and Books.

Constantly updated with the latest and greatest tools. Check it out!

Categories

Rey Bango is Stephen Fry proof thanks to caching by WP Super Cache
